Availability: | |
---|---|
Quantity: | |
Applications:
HOWO 8x4 Mixer Truck is suitable for urban construction, highway, railway,and other departments. With 400/430HP engine, the HOWO 8x4 Mixer Truck is one of indispensable important equipment of the mechanized construction.
Production Description:
The Howo 8x4 mixer truck is a truck used to transport concrete for construction. HOWO 8x4 Mixer Truck is equipped with a cylindrical mixing tank to carry the mixed concrete. Howo series mixers adopt strong and firm mixing tanks and different volumes. With 6cbm、10cbm、 12cbm、 16cbm 、20cbm for your choose, it could fully meets the needs of different users. the structure of mixer truck is compact and reasonable, and its performance is stable and reliable. The cab is luxurious, beautiful, safe and comfortable. Howo mixer truck is applicable to various construction sites and other construction sites.
Specification Sheet:
Model | ZZ1317M3261W | ZZ1317N3667A | |||
Cab | Model | HW76 | |||
Type | HW76 extend cab, one berth, with A/C all steel forward control, 55°hydraulically tiltable to the front,2-arm windscreen wiper system with 3 speeds, laminate windscreen, with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, adjustable roof flap, with stereo radio/cassette recorder, sun visor, and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorber with transverse stabilizer, safety belt. | ||||
Engine | Model | WP12.400E201 | WP12.430E201 | ||
Rated power | 400HP (294Kw/rpm) | 430HP(316Kw/rpm) | |||
Displacement | 9.726L | ||||
Type | 6 cylinder in-line with water cooling, turbo-charging & intercooling | ||||
Wheelbase | 1800+3200+1400mm | 1800+3600+1400mm | |||
Mixer tanker size | 12CBM-16CBM | ||||
Clutch | Single- plate dry diaphragm spring clutch, diameter 430(C) mm, hydraulically operating with air assistance | ||||
Transmission | SINOTRUK HW series 10/12/16 speed transmission, 10 forward and 2 reverse | ||||
Front axle | Steering axle with double T-cross section HF9 | ||||
Drive axle | Pressed axle housing, central single reduction HC16/AC16 | ||||
Chassis | Frame: U-profile parallel ladder type with section of 320×90×8 mm, all cold riveted cross members and reinforced subframe | ||||
Steering | Germany ZF, hydraulic steering with power assistance | ||||
Brakes | Service brake: dual circuit compressed air brake | ||||
Wheel & Types | Rims: 8.0-20, 10 hole-steel | ||||
Electrics | Operating voltage:24V, negative grounded; Starter: 24V, 5.4KW |
