Product Description:
3 axles 45CBM 60 tons bulk cement bulker tanker truck trailer is used to transport bulk powder such as cement, flyash, and other powder which is smaller than 1mm.
It is cement tank trailer, and we can also supply cement tanker truck.
The cement bulker trailer is able to delivery more cement by one trip, and save packaging cost for the user.
Main specification:
Trailer Model | 45 M3 CEMENT BULKER TRAILER |
Overall Dimension (LxWxH)(mm) | 12000x2500x3900mm bulk cement |
Function | transport bulk powder |
Thickness (mm) | 5mm Carbon steel Q235B |
Loading Weight (KG) | 60000KGS BULK CEMENT TANKER |
Axle | 3x13Ton, FUWA brand |
Air compressor | 37 KW,0.2Mpa. 1000r/Min (12m3/minute) Bohai brand |
Diesel engine | Diesel engine: Weichai brand |
Compartment | 1 inner fluidized bed: air bag |
Manhole cover | 500mm manhole cover |
Suspension system | Standard Mechanical suspension |
Steel Spring | -10/10/10 leaf spring suspension |
Tire | 12R22.5 12units tubeless tire |
Traction Pin | 50mm or 90mm optional |
Spare Wheel Bracket | 2 pieces |
Tool Box | 1 Standard |
Landing Gear | Standard 28 tons |
Brake system | Dual Line braking system |
Brake air chamber | WABCO brand, Six big double air chambers |
Electrical system | 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) |
Tail lamp with turn signal, brake light & reflector, side lamp etc. | |
One set 6-core standard Cable. | |
Side Guard | According to customer's requirement |
Painting | According customer requirement |
Packing | Polish with wax before shipping |
Product Description:
3 axles 45CBM 60 tons bulk cement bulker tanker truck trailer is used to transport bulk powder such as cement, flyash, and other powder which is smaller than 1mm.
It is cement tank trailer, and we can also supply cement tanker truck.
The cement bulker trailer is able to delivery more cement by one trip, and save packaging cost for the user.
Main specification:
Trailer Model | 45 M3 CEMENT BULKER TRAILER |
Overall Dimension (LxWxH)(mm) | 12000x2500x3900mm bulk cement |
Function | transport bulk powder |
Thickness (mm) | 5mm Carbon steel Q235B |
Loading Weight (KG) | 60000KGS BULK CEMENT TANKER |
Axle | 3x13Ton, FUWA brand |
Air compressor | 37 KW,0.2Mpa. 1000r/Min (12m3/minute) Bohai brand |
Diesel engine | Diesel engine: Weichai brand |
Compartment | 1 inner fluidized bed: air bag |
Manhole cover | 500mm manhole cover |
Suspension system | Standard Mechanical suspension |
Steel Spring | -10/10/10 leaf spring suspension |
Tire | 12R22.5 12units tubeless tire |
Traction Pin | 50mm or 90mm optional |
Spare Wheel Bracket | 2 pieces |
Tool Box | 1 Standard |
Landing Gear | Standard 28 tons |
Brake system | Dual Line braking system |
Brake air chamber | WABCO brand, Six big double air chambers |
Electrical system | 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) |
Tail lamp with turn signal, brake light & reflector, side lamp etc. | |
One set 6-core standard Cable. | |
Side Guard | According to customer's requirement |
Painting | According customer requirement |
Packing | Polish with wax before shipping |
