42CBM Aluminum Alloy 3 Axle Oil Tanker Trailer

Overall Dimension

12500x2500x3700 mm

Use for

Fuel, Oil, Diesel

Thickness(mm)

Tank body

 5083 aluminum alloy

End plate

5083 aluminum alloy

Loading(L)

60,000

Axle Brand

FUWA Brand 13Ton Axle

Axle Number

3 or 4

Compartment

2 or 3, for optional

Manhole cover

Standard 500mm

Discharge valve

4"

Emergency valve

4"

Suspension

Mechanical suspension

Main beams

Opting for high tensile steel Q345B welded by automatic submerged - arc processes

Main beam

The height of the beam

500 mm

upper plate is

14mm

down plate

16mm

middle plate

8mm

Tire Tire and quantity

12R22.5 triangle brand 12units

Traction Pin

2' or 3.5' for optional

Spare Wheel Bracket

2 pieces

Tool Box

1 Standard

Landing Gear

28ton

Brake system

Break system: double line air breaks with spring loaded parking brake, air parking brake

Brake chamber

6 relay valve; T30/30+T30 Spring brake chamber; one piece of 45L air tanks

air chamber

Six big double air chambers

Bumper

heavy-duty bumper at the rear

Loading

bottom and top loading

Electrical light

electrical equipment 24 Volt, in accordance with the road traffic regulations electric connection type SAE 7 poles mounted on the front bearer.
Position light, mount on front bear and side marker lights, round tail light with steel ring fixed by rivet.

Walkway

for easy access to manholes covers(material is carbon steel)

Access ladder

one(1) access ladder at front of tank.
