Applications:HOWO 50T Mining Dump Truck specially designed for optimal performance and effectiveness the mining operations.
Product description:
The HOWO 50T Mining Dump Truck is a powerful and reliable vehicle designed to tackle tough terrain and large loads. With its robust construction, powerful engine, and advanced technology, this truck is capable of operating in even the most challenging conditions. Its spacious cab, comfortable seats, and cutting-edge safety features ensure a smooth and safe ride for drivers and passengers alike. From hauling large quantities of minerals to working on construction sites, the HOWO 50T Mining Dump Truck is the perfect choice for heavy-duty work.
Specification Sheet:
Truck Model | ZZ5707S3640AJ | ZZ5707S3840AJ | |||
Dimension | Cargo body size (LxWxH) (mm) | 5600x3100x1800mm | 5800x3100x1800mm | ||
HYVA 196 full cylinder front-lifting, side 12 mm bottom 10 mm, 16Mn martial, protective frame on both sides of the fence and defensive drill. | |||||
Wheel base (mm) | 3600+1500 | 3800+1500 | |||
Overhang(front/rear) (mm) | 1500/1800 | ||||
Min ground Clearance | 340 | ||||
Approaching angle/Departure angle（°） | 32/40 | ||||
Mass Parameters | Curb weight（kg） | 23000 | |||
Loading Weight(kg) | 50000 | ||||
Performance Parameters | Max speed (Km/h) | 50 | |||
Max Grade ability (%) | 42 | ||||
Min turning Radius (m) | 22 | ||||
Cab | HW7D | ||||
Engine | Model | 47T2 | |||
Rated Power kW/r/min） | 371HP | ||||
Max Torque（N.m/r/min) | 1500/1100～1600 | ||||
Clutch | GF430A | ||||
Transmission | Model | HW21712 | |||
Rear axle | Enhanced wide-body twin steel double reduction driving axle AC16 | ||||
Front axle | Overall steel reinforced front axle HF10 | ||||
Tire | 13.00-25 | ||||
Fuel tanker capacity | 500L | ||||
Cabin | HW7D Sketch covering, grand view and single side reinforced mine truck dedicated cab, Suspension is helical spring with shock absorber, are conditioner and heater. Heating system fit for cold areas is optional. | ||||
