Applications:
The 3 Axles Goose Neck Semi Trailer is designed for stevedoring and transporting Cargos..
Production Description：
3 Axles Goose Neck Semi Trailer With is a heavy-duty vehicle used to transport large and heavy goods. 3 Axles Goose Neck Semi Trailer is equipped with three axles, which distribute the weight evenly and allow for better load capacity.
Specification Sheet:
| External Dimensions | Length: Approx 14,000 mm |
| Width: Approx 2,500 mm (including mud guard) | |
| Height: Approx 4,200mm | |
| King Pin Location: Approx 750mm from the front face of the front bolster | |
| Axle spacer: Approx 9,152 mm+1,360mm+1,360mm | |
| Landing Gear location: 2,440mm behind the king pin location | |
| Fifth wheel (King Pin) Height: Approx 1,315mm with the chassis level | |
| Internal Dimensions | Length: Approx 13650mm |
| Width: Approx 2,400 mm | |
| Height: Approx Front 2,700mm, Rear 3175mm(not confirmed) | |
| Steel Structure | Main Beam Material: High Tensile strength steel T700 is used for welded I-beam, Q345 and Q235 is used for the fabricated parts. |
| Top Flange:12mm | |
| Bottom Flange:12mm | |
| Web: 6mm. | |
| Platform: checkered steel floor, the thickness is 3mm. | |
| Front End Wall: | |
| Front Frame: Steel Frame, Corner steel post. | |
| Front End Wall: Steel Sheet . | |
| Rear End Door： | |
| Rear Frame: Steel Frame | |
| Rear Door: two doors | |
| Body | Side Wall Assembly: |
| Top Track: Al track. | |
| Side Wall: Curtain. | |
| Curtain Rubber Tape: Waterproof fabric better. | |
| Sliding Post: 2 units per side | |
| Roof: | |
| Made of aluminum, thickness 1mm. | |
| Fence(Gate): 12 units, 2m tall. | |
| Weight | Tare Weight (Tolerance 0~-4%): Approx 10,500 kg |
| Max Payload: Approx 30,000 kg | |
| Gross Vehicle Weight: Approx 40,500 kg | |
| OEM Parts Configuration | King Pin: 2” bolted exchangable king pin. Brand: JOST. Made in China. |
| Landing Gear: 2 speed, Linked action, one side operated, rocket feet. Rated Lift Load Capacity: 30T. Rated Ultimate Load Capacity:80T. | |
| Suspension: Air suspension, Chinese famous brand. Type: L1, without lifting. | |
| Axles: 13 tons square axle. | |
| Rims: 9.00-22.5, equip 13 per chassis. ISO standard, 10 holes. | |
| Tires: 12R22.5, equip 13 per chassis, Chinese famous brand. | |
| Brake System: Dual air brake system, WABCO relay valve, with ABS system. | |
| Brake chamber: Type 30/30 on the all axles. | |
| Electrical System: 24volt lighting system, 7-way receptacle, ISO standard. | |
| Others | Side guard: None. |
| Fence(Gate) Carrier: Yes. | |
| Tool Box: None. | |
| Spare Tire Carrier: 2 pcs with crank handle. | |
| Marking: Technical data plate including chassis no, dead weight, year of manufacturing etc. to be fitted | |
| Painting: colored by customer’s request | |
| Water tank: None | |
| Reflector: one roll put in container, customer stick according to local law. |
